Special Offers for youGet best deal on ACE
6000 Kg
3 Meter
ACE AF 60E Specifications
ACE AF 60E is an industrial vehicle designed for the purpose of lifting, moving, and stacking materials. ACE AF 60E plays a vital role in material handling operations across various industries.
ACE AF 60E Engine Rating
The engine rating of ACE AF 60E promises better performance with a maximum horsepower.
Fuel Type of ACE AF 60E
The ACE AF 60E fuel type is Electric offering increased work efficiency and lower operating costs in the long run.
Lifting Load Capacity of ACE AF 60E
ACE AF 60E lifting load capacity is 6000 Kg enabling businesses to achieve greater efficiency, flexibility, and profitability in their operations.
ACE AF 60E Lift Height
ACE AF 60E comes with an ideal lift height that contributes to improved productivity.
ACE AF 60E Ground Clearance
ACE AF 60E ground clearance is 160 Kg which allows you to effortlessly navigate diverse terrains, including rough or uneven surfaces.
ACE AF 60E Price in India
ACE AF 60E crane price in India starts from ₹ 45 Lakh
6000 Kg3 Meter
1070 mmCheck all ACE Equipments
Lifting load capacity6000 Kg
Lift height3 Meter
Length to face of forks1070 mm
Turning radius2817 mm
Ground Clearance160 mm
General | |||
|---|---|---|---|
| Lifting Load Capacity | 6000 Kg | ||
| Load Center Distance | 500 mm | ||
| Fuel Type | Electric | ||
Tyres | |||
|---|---|---|---|
| Size Front | 2.8x12.5-15-24PR | ||
| Size Rear | 7.00-12-14PR | ||
| Wheel Base | 2000 mm | ||
Dimensions | |||
|---|---|---|---|
| Lift Height | 3 Meter | ||
| Std. free Lift | 150 mm | ||
| Fork L*W*T (mm^3) | 1070 mm | ||
| Turning Radius | 2817 mm | ||
| Height | 4160 mm | ||
| Overhead Guard Height | 2255 mm | ||
| Overall width | 1600 mm | ||
| Length to face of forks | 1070 mm | ||
Performance | |||
|---|---|---|---|
| Lifting (m/s) | 300 MM/S | ||
| Lowering (m/s) | 220 MM/S | ||
| Steering Type | Hydraulic Steering | ||
| Gradability | 15 % | ||
Brakes | |||
|---|---|---|---|
| Parking Brakes Type | Mechanical-Hand Lever | ||
| Service Brakes Type | Hydraulic-Foot Pedal | ||
