ESCORTS F25 FIGHTER

Escorts F25 Fighter combines 4WD, a 40 km/h top speed and an 8.25 m turning radius for moving between material handling locations. Its shorter turning radius also makes positioning easier around congested construction areas.

The four part boom uses three hydraulically powered sections while the fourth section is power extended and manually pinned. This arrangement allows operators to adjust boom reach according to the load placement point.

For controlled crane operation, the Safe Load Indicator with hydraulic cut off monitors lifting conditions and restricts operation during unsafe loading. The counter balance protection valve also prevents sudden boom lowering after a lift line hose failure.

Meanwhile, the rear view camera and 7 inch TFT display improve visibility when positioning or reversing. The optional 5 ton drag winch further adds horizontal pulling capability for shifting materials across the working area.

Escorts F25 Fighter Price in India

Looking for the latest Escorts F25 Fighter price in India? The final price can vary based on configuration, location and applicable commercial terms.

On Infra Junction, you can compare Escorts F25 Fighter specifications, explore crane capabilities and check available options. You can also compare cranes and connect with Escorts crane dealers for quotations.

Escorts F25 Fighter Key Specifications

Engine and Powertrain

• Engine: The VECV E494 CEV Stage V engine develops 101 hp at 2200 RPM.
• Transmission: The 10F+2R synchromesh transmission provides ten forward and two reverse speeds for controlled machine movement.
• Drive: Four wheel drive provides stronger traction when the crane needs to reach lifting points across loose, uneven or low grip surfaces.
• Clutch: The pneumatically assisted hydraulic clutch reduces the effort required to operate the single dry friction clutch.

Lifting Capacity and Reach

• Maximum Lifting Capacity: Escorts F25 Fighter lifts 25 tonnes at a 1.5 metre radius for handling heavier structural and industrial loads.
• Extended Radius Capacity: Its 0.9 tonne rating at 16.6 metres allows lighter loads to be placed farther from the crane.
• Boom Height: The 22.3 metre height with fly jib allows elevated material placement during structural erection and installation work.
• Lifting Range: The boom operates from -3° to +65° to provide different boom positions for load placement.

Boom and Hoist

• Four Part Boom: Three sections extend hydraulically and synchronously while the fourth section power extends and is manually pinned for safety.
• 15 Ton Hoist: The hydraulically operated six fall hoist provides the lifting arrangement needed for heavy material handling.
• Auto Levelling Hook Block: The hook block automatically levels during boom extension and retraction to keep the hook correctly positioned during load handling.
• Built In Hoist Brakes: Safety brakes within the hoist provide braking control during lifting operations.

Mobility and Manoeuvrability

• 40 km/h Maximum Speed: The high travel speed allows quicker relocation between lifting areas on large construction and infrastructure sites.
• 1.3 km/h Creep Speed: Low speed movement gives better control while approaching a load or positioning the crane at a lifting point.
• 8.25 m Turning Radius: The short turning radius helps the crane manoeuvre around restricted work areas and congested project sites.
• 36% Gradeability: The stated unladen gradeability allows the crane to negotiate inclined access routes when travelling without a load.

Operator Cabin and Visibility

• All Weather Cabin: The weatherproof cabin provides unrestricted visibility while protecting the operator during site operations.
• Rear Camera and LCD: The rear view camera gives the operator a clearer view behind the crane while reversing or positioning.
• 7 Inch TFT Display: The display shows the rear camera view that allows the operator monitor the area behind the machine.
• Electronic Accelerator Pedal: The low effort pedal reduces foot effort during repeated crane movement.
• Hydro Pneumatic Clutch: Pneumatic assistance reduces clutch operating effort during machine operation.

Optional Equipment and Safety

• 5 Ton Drag Winch: The optional drag winch allows horizontal pulling or dragging of loads where this function is required.
• Man Carrying Basket: The optional basket provides an attachment for designated personnel lifting applications.
• Outrigger Home Position Sensor: The system gives an audio visual alert when an outrigger moves from its home position.
• Mandatory Outrigger Alert: The system warns the operator to deploy outriggers when the boom is raised for higher height operations.
• Forward Movement Restriction: The system provides an audio alert when forward movement occurs with the outriggers open.
• Smart Telematics: The optional system can integrate SLI data with the telematics server and mobile application.
