JCB NXT 245HDLR

Rating Icon5
4 Reviews
Write a Review

JCB NXT 245HDLR is a 140 HP tracked excavator with a 23850 kg operating weight. It comes with a 0.45 cu.m heavy duty bucket and 15.62 m maximum digging reach. Its IntelliControl system offers three power modes while ecoHYDRAULICS helps reduce hydraulic losses and fuel use. The machine also gets JCB LiveLink for monitoring operations, maintenance and security.

JCB NXT 245HDLR
Price Coming Soon
Engine Power140 HpOperating Weight23850 KgBucket capacity0.45 Cum

Check all JCB Equipments

arrow_icon
AD

JCB NXT 245HDLR Specification

Engine PowerEngine Power

140 Hp

Operating WeightOperating Weight

23850 Kg

Bucket capacityBucket capacity

0.45 Cum

Hydraulic systemHydraulic system

220 Lpm

Maximum Digging DepthMaximum Digging Depth

12040 MM

About JCB NXT 245HDLR Excavator Overview

JCB NXT 245HDLR is a 140 HP tracked excavator designed for heavy duty digging, earthmoving and material handling. It has a maximum operating weight of 23850 kg with 800 mm tracks.

Powered by a 5.88 litre Cummins 6BT 5.9C engine, it delivers 140 HP at 2000 rpm. Its hydraulic system uses two variable displacement axial piston pumps with a combined maximum flow of 440 L/min.

JCB NXT 245HDLR offers 15.62 m maximum digging reach and 12.04 m digging depth. Its 65.5 kN bucket breakout force supports demanding excavation work.

IntelliControl provides P+, P and Eco power modes for different workloads. ecoHYDRAULICS, regenerative hydraulic circuits and Auto idler help manage fuel use during longer cycles. JCB LiveLink telematics also tracks fuel, operating hours, maintenance status and machine health.

JCB NXT 245HDLR Excavator Price in India

JCB NXT 245HDLR price in India depends on the machine setup and the optional features selected. Buyers can check the latest quotation and available configurations through authorised JCB dealers.

On Infra Junction, you can check detailed specifications, view images, compare features and connect with verified JCB excavator dealers for the latest price quotes. You can also compare different machine options to find the right excavator for your work.

JCB NXT 245HDLR Excavator Key Specifications

Engine and Performance

  • Engine: JCB NXT 245HDLR uses a Cummins 6BT 5.9C diesel engine with 5.88 litre displacement.
  • Power: The engine produces 140 HP at 2000 rpm for demanding excavation work.
  • Power Modes: P+, P and eco modes let operators balance output and fuel use according to the job.
  • Operating Weight: Maximum operating weight reaches 23850 kg with 800 mm tracks.

Digging and Excavation

  • Deep excavation: The 12.04 m maximum digging depth supports projects that require deeper excavation.
  • Extended working reach: Its 15.62 m maximum reach provides a wider working area.
  • Material loading: The 10.4 m maximum load over height helps place excavated material into trucks or other locations.
  • Heavy duty bucket: The 0.45 cu.m bucket handles regular excavation and material handling work.

Fuel Efficiency and Productivity

  • ecoHYDRAULICS: The system reduces hydraulic losses to improve fuel use during machine operation.
  • Regenerative Circuit: Hydraulic oil is redirected through the boom circuit to support faster operating cycles.
  • Auto Idler: The system automatically reduces engine speed when the machine is not working to reduce unnecessary fuel use.
  • One Touch Deceleration: A single switch operation reduces engine rpm when full engine output is not required.

Operator Comfort and Safety

  • Cabin: The cabin gets a fully ducted air conditioner with a heater for improved temperature control.
  • Ventilation: An assisted roof hatch helps increase airflow inside the cabin.
  • Vibration Control: Six viscous mounts help reduce vibration reaching the operator.
  • Controls: Rotary switch controls and a low effort joystick simplify machine operation.
  • Lighting: Five working lights provide illumination for operations in low light conditions.
  • Safety: A hydraulic interlock prevents engine starting unless the required safety conditions are met.
  • Protection: A cabin top guard, fire extinguisher and first aid kit are included as standard equipment.

Why Choose Infra Junction for JCB NXT 245HDLR Excavator?

Infra Junction helps buyers compare JCB NXT 245HDLR specifications, features and equipment options in one place. You can check its engine power, bucket capacity, digging range, hydraulic performance and operating weight.

The platform also helps users compare construction equipment based on the work they need to perform. Buyers can explore new and used JCB machines and connect with dealers for the latest quotations.

‌

JCB NXT 245HDLR Features

Engine
ModelCUMMINS6BT 5.9C
Displacement5.88 L
Engine Power140 Hp
Hydraulic System
Main system Maximum Flow220 Lpm
